6 x K41WS-IWRC Wire Ropes

the most flexible compacted 6-strand construction available with a steel rope core. Designed for extreme-duty offshore, deep-sea, and heavy crane applications. Available from 10mm to 60mm across grades 1570–2160 MPa.

Brand – Mega Link
Usage/Application – Heavy cranes, offshore, deep sea — extreme flexibility with steel core

Color – Bright (Ungalvanised) / Galvanised
Material – High Carbon Steel (Carbon 0.4–1%, Manganese 0.3–1%)
Country Of Origin – India

Standard – IS / EN 12385

Specification – 6 strands × Compacted K41WS construction, IWRC

Download Brochure
Enquire Now

Description

Technical Data (Refer to 6×K19S-IWRC table.)

Nominal Rope Diameter (mm)	Approx Weight WC (kg/100m)	MBL 1570 WC (kN)	MBL 1670 WC (kN)	MBL 1770 WC (kN)	MBL 1870 WC (kN)	MBL 1960 WC (kN)	MBL 2160 WC (kN)
10	46.5	65.2	69.3	73.5	77.6	81.3	89.6
12	67.0	93.8	99.8	106	112	117	129
14	91	128	136	144	152	159	176
16	119	167	177	188	199	208	230
18	151	211	225	238	251	264	290
20	186	261	277	294	310	325	359
22	225	315	335	356	376	394	434
24	268	375	399	423	447	469	516
26	314	440	469	497	525	550	606
28	365	511	543	576	608	638	703
30	419	586	624	661	698	732	807
32	476	667	710	752	795	833	918
34	538	753	801	849	897	940	1040
36	603	844	898	952	1010	1050	1160
38	671	941	1000	1060	1120	1170	1290
40	744	1040	1110	1180	1240	1300	1430
42	820	1150	1220	1300	1370	1430	1580
44	900	1260	1340	1420	1500	1570	1740
46	984	1380	1470	1550	1640	1720	1900
48	1070	1500	1600	1690	1790	1870	2070
50	1160	1630	1730	1840	1940	2030	2240
52	1260	1760	1870	1990	2100	2200	2420
54	1360	1900	2020	2140	2260	2370	2610
56	1460	2040	2170	2300	2430	2550	2810
58	1560	2190	2330	2470	2610	2740	3020
60	1670	2350	2490	2640	2790	2930	3230
