Description

Technical Data

6 x 25F-FC

Nominal Rope Diameter (mm)	Approx Weight FC (kg/100m)	MBL 1570 FC (kN)	MBL 1770 FC (kN)	MBL 1960 FC (kN)	MBL 2160 FC (kN)
6	13.7	18.7	21.0	23.3	25.7
7	18.6	25.4	28.6	31.7	34.9
8	24.3	33.2	37.4	41.4	45.6
9	30.8	42.0	47.3	52.4	57.7
10	38.0	51.8	58.4	64.7	71.3
11	46.0	62.7	70.7	78.3	86.2
12	54.7	74.6	84.1	93.1	103
13	64.2	87.6	98.7	109	120
14	74.5	102	114	127	140
16	97.3	133	150	166	182
18	123	168	189	210	231
20	152	207	234	259	285
22	184	251	283	313	345
24	219	298	336	373	411
26	257	350	395	437	482
28	298	406	458	507	559
32	389	531	598	662	730
36	492	671	757	838	924
40	608	829	935	1030	1140
44	736	1000	1130	1250	1380
48	876	1190	1350	1490	1640
52	1030	1400	1530	1750	1930
56	1190	1620	1830	2030	2240

6 x 25F-IWRC

Technical Data

Nominal Rope Diameter (mm)	Approx Weight WC (kg/100m)	MBL 1570 WC (kN)	MBL 1770 WC (kN)	MBL 1960 WC (kN)	MBL 2160 WC (kN)
6	15.0	20.1	22.7	25.1	27.7
7	20.5	27.4	30.9	34.2	37.7
8	26.8	35.8	40.3	44.7	49.2
9	33.9	45.3	51.0	56.5	62.3
10	41.8	55.9	63.0	69.8	76.9
11	50.6	67.6	76.2	84.4	93.0
12	60.2	80.5	90.7	100	111
13	70.6	94.5	106	118	130
14	81.9	110	124	137	151
16	107	143	161	179	197
18	135	181	204	226	249
20	167	224	252	279	308
22	202	271	305	338	372
24	241	322	363	402	443
26	283	378	426	472	520
28	328	438	494	547	603
32	428	572	645	715	787
36	542	724	817	904	997
40	669	894	1010	1120	1230
44	809	1080	1220	1350	1490
48	963	1290	1450	1610	1770
52	1130	1510	1700	1890	2080
56	1310	1750	1980	2190	2410
