DLC Horizontal Lifting Clamp

Brand – Mega Link
Usage/Application – Horizontal lifting of H, T, I, and L shaped structured steel
Material – Die-forged special alloy steel
Color – Red
Country Of Origin – India Standard
Specification
  • Working load limit (WLL) 1–3 ton
  • Clamp for horizontal lifting of “H”, “T”, “T”, “L” shaped structured steel
  • Compact, lightweight, easy to use design from a mechanics point of view
  • Main body and parts made from die-forge special alloy steels, optimally tempered for maximum strength and durability
Download Brochure
Enquire Now
Category:

Description

The DLC Horizontal Lifting Clamp is designed for the horizontal lifting of H, T, I, and L shaped structural steel sections. Compact and lightweight, it is manufactured from die-forged special alloy steel, optimally tempered for maximum strength and durability, with WLL up to 3 tonnes per pair.

Technical Data

Model WLL (t) per Pair Jaw Opening (mm) Net Weight (kg)
DLC-1 1.0 1–13 2.1
DLC-2 2.0 3–22 4.7
DLC-3 3.0 12–35 8.0
